Heavy Duty Slab Grabber
SKU: OCM-GRP-HD
OCM, Inc's Heavy Duty Slab Grabber are used as guardrails that are fast, easy, and affordable.
Made from high-strength galvanized steel; capable of withstanding at least 200 lbs. The Heavy-Duty Slab Grabber meets FEDERAL OSHA 1926 502(B)(3) requirements.
Features
- Quick adjust handle and rugged steel construction for fast attachment and construction for fast attachment and a positive grip on the slab
- Bracket preinstalled to mount toe board when required or when surface slope is when required or when surface slope is more than 4/12 (vertical/horizontal) and if there is a risk of any type of work material to fall to a lower level
- Adjustable for use on up to 29" slabs
- Maximum spacing of 8 ft per OSHA spec
- Height from top of slab to top of rail is 46"
- Meets FEDERAL OSHA 1926 502(B)(3) requirements.
- Capable of withstanding at least 200 lbs. applied within 2" of the top edge, in any downward direction, at any point along the top edge.
| OCM Part No. | Description | Weight lbs. | Skid |
|---|---|---|---|
| OCM-GRP-HD | Guard Rail Post Bracket - Heavy Duty Galvanized | 26.00 | 200 |
*WARNING: Rail Post must be secured to deck with proper fasteners to ensure safety.
*WARNING: Use of equipment for unintended applications could result in serious injury or death.
NEVER make any connections to guardrail system.
*WARNING: NEVER lean or climb on guardrail systems.
