Coil Nuts
SKU: 50ACCN0P
OCM Coil Nuts are made from high strength steel and are used with different types of coil thread bolts and rods in concrete formwork, bridge deck forming, or precast concrete applications.
Features
- Can be provided in different sizes from 1/2" to 1 1/2"
- Standard is provided with Right Hand Thread, but left hand is also available
- Coil Thread is self-cleaning and ideal for dirty jobsites or use in concrete formwork
| OCM Part No. | D Size | H Height | AC Across Flats | Box Qty | Weight per 100pcs lbs. | Safe Working Load lbs. |
|---|---|---|---|---|---|---|
| 50ACCN0P | 1/2" | 0.484 | 0.863 | 500 | 6.2 | 6,000 |
| 50ACCN0P-G | 1/2" | 0.484 | 0.863 | 500 | 6.2 | 6,000 |
| 62SFCN | 5/8" Finished | 0.547 | 0.93 | 500 | 11.4 | 8,000 |
| 75SFCN | 3/4" Finished | 0.641 | 1.107 | 500 | 11.4 | 12,000 |
| 75SCCN0P | 3/4" Heavy | 0.734 | 1.231 | 250 | 17.8 | 12,000 |
| 87SCCN0P | 7/8" | 0.859 | 1.416 | 250 | 27.6 | 16,000 |
| 100SCCN0P | 1" | 0.984 | 1.6 | 150 | 15 | 24,000 |
| 125SCCN0P | 1-1/4" | 1.219 | 2.123 | 70 | 75.2 | 36,000 |
| 150CCCN | 1-1/2" | 1.50 | 2.375 | 40 | 129 | 47,500 |
