Aluminum Yard Ramps - Steel Grading
SKU: SY-167230
Portable Aluminum Yard Ramps have a unique design that allows one person to position the ramp, adjust its service height, and load or unload trailers from ground level.
Available with steel or rust resistant aluminum grating. Standard features: Manual hydraulic hand pump (safety pressure relieft valve),18" x 5" mold-on-rubber tires, 4" high curbs, service range of 45" to 62", anchor chains, and tow bar pocket. Yard ramps ship flatbed truck. (Yellow guards are optional)
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
| Aluminum Yard Ramps - Alum. Grating | |||||||
| Model | Image | PDFs | Capacity (lbs) |
Overall Width |
Usable Width |
Length | Wt. (lbs) |
| AY-167230 |  |

|
16,000 | 74" | 66" | 30' | 2783 |
| AY-168430 |  |
|
16,000 | 86" | 78" | 30' | 3150 |
| AY-169330 |  |
|
16,000 | 95" | 87" | 30' | 3465 |
| AY-167236-L |  |
|
16,000 | 74" | 66" | 36' | 3360 |
| AY-168436-L |  |
|
16,000 | 86" | 78" | 36' | 3728 |
| AY-169336-L |  |
|
16,000 | 95" | 87" | 36' | 3990 |
| AY-207230 |  |
|
20,000 | 74" | 66" | 30' | 3565 |
| AY-208430 |  |
|
20,000 | 86" | 78" | 30' | 3255 |
| AY-209330 |  |
|
20,000 | 95" | 87" | 30' | 3570 |
| AY-207236-L |  |
|
20,000 | 74" | 66" | 36 | 3465 |
| AY-208436-L |  |
|
20,000 | 86" | 78" | 36' | 3833 |
| AY-209336-L |  |
|
20,000 | 95" | 87" | 36' | 4095 |
| AY-257230 |  |
|
25,000 | 74" | 66" | 30' | 2940 |
| AY-258430 |  |
|
25,000 | 86" | 78" | 30' | 3308 |
| AY-259330 |  |
|
25,000 | 95" | 87" | 30' | 3675 |
| AY-257236-L |  |
|
25,000 | 74" | 66" | 36' | 3578 |
| AY-258436-L |  |
|
25,000 | 86" | 78" | 36' | 3885 |
| AY-259336-L |  |
|
25,000 | 95" | 87" | 36' | 4200 |
| AY-307230 |  |
|
30,000 | 74" | 66" | 30' | 3092 |
| AY-308430 |  |
|
30,000 | 86" | 78" | 30' | 3360 |
| AY-307236-L |  |
|
30,000 | 74" | 66" | 36' | 3570 |
| AY-308436-L |  |
|
30,000 | 86" | 78" | 36' | 3938 |
| Aluminum Yard Ramps - Steel Grating | |||||||
| SY-167230 |  |
|
16,000 | 74" | 66" | 30' | 3518 |
| SY-168430 |  |
|
16,000 | 86" | 78" | 30' | 4043 |
| SY-169330 |  |
|
16,000 | 95" | 87" | 30' | 4515 |
| SY-167236-L |  |
|
16,000 | 74" | 66" | 36' | 4305 |
| SY-168436-L |  |
|
16,000 | 86" | 78" | 36' | 4830 |
| SY-169336-L |  |
|
16,000 | 95" | 87" | 36' | 5303 |
| SY-207230 |  |
|
20,000 | 74" | 66" | 30' | 3623 |
| SY-208430 |  |
|
20,000 | 86" | 78" | 30' | 4148 |
| SY-209330 |  |
|
20,000 | 95" | 87" | 30' | 4620 |
| SY-207236-L |  |
|
20,000 | 74" | 66" | 36' | 4410 |
| SY-208436-L |  |
|
20,000 | 86" | 78" | 36' | 4935 |
| SY-209336-L |  |
|
20,000 | 95" | 87" | 36' | 5408 |
| SY-257230 |  |
|
25,000 | 74" | 66" | 30' | 3675 |
| SY-258430 |  |
|
25,000 | 86" | 78" | 30' | 4200 |
| SY-259330 |  |
|
25,000 | 95" | 87" | 30' | 4725 |
| SY-257236-L |  |
|
25,000 | 74" | 66" | 36' | 4463 |
| SY-258436-L |  |
|
25,000 | 86" | 78" | 36' | 4988 |
| SY-259336-L |  |
|
25,000 | 95" | 87" | 36' | 5513 |
| SY-307230 |  |
|
30,000 | 74" | 66" | 30' | 3728 |
| SY-308430 |  |
|
30,000 | 86" | 78" | 30' | 4253 |
| SY-307236-L |  |
|
30,000 | 74" | 66" | 36' | 4515 |
| SY-308436-L |  |
|
30,000 | 86" | 78" | 36' | 5040 |
KEY: = Approval Drawing --
= Warranty -- = Testing Certificate
