CC5555GK Rear Pivot Walk Behind Saw

Features & Benefits:
• Kubota® liquid-cooled gasoline WG1605 LSI engine that is fully complaint with EPA regulations
• Murphy PV480, 4.3" controller display
• Easy to maneuver rear-pivot self-propelled drive
• 4-position handlebar setup (0°, 15°, 30°, 45°)
• 3-Speed gear box standard
• Pull/twist-lock for rear positraction and transmission neutral
• Quick release blade shaft & flange
• Heavy duty crated steel frame base for increased rigidity
• Square tube skeletal upright frame for improved strength
• Removable access panels for easy, access to speed routine maintenance
• Electronic depth display and stop function
• Toggle switch throttle control

CC555GK Specifications
Max.Depth of Cut with 14" Blade	3-3/4"
Max. Depth of Cut with 20" Blade	6-3/4"
Max. Depth of Cut with 26" Blade	9-3/4"
Max. Depth of Cut with 30" Blade	11-3/4"
Max. Depth of Cut with 36" Blade	14-3/4"
Arbor Size	1" with single drive pin
Blade Shaft Drive	7 belts
Blade Mounting	Right or left
Blade Raise/Lower	Electro-hydraulic pump
Fuel Tank	5.5 gallon with digital fuel display
Transmission	Eaton Model 7
Drive Speed	0-368 feet per minute
Includes	Blade shaft tachometer, hour meter, Frame Lift, Cutting depth indicator, Quick disconnect blade flanges, Telescoping front pointer, GM gel battery, Removable panels

Blade Capacity	Motor/Engine Power	Engine/Motor Make	Power Source	Part Number	Catalog Number
14"	Gasoline	Kubota®	Gas	5802300	84977
20"	Gasoline	Kubota®	Gas	5802301	84978
26"	Gasoline	Kubota®	Gas	5802302	56861
30"	Gasoline	Kubota®	Gas	5802303	84985
36"	Gasoline	Kubota®	Gas	5802304	56912
