- Dump and drive capability allows for feathering of load in forward and reverse.
- Operator's platform with simple and clean control system allows for comfortable and convenient operation of the unit.
- Excellent traction and control with heavy-duty welded chassis.
- High density poly bucket (DB17) is impact resistant and designed to withstand the toughest use.
- Steel bucket is standard on DB21, option for DB17.
- Power supplied through heavy-duty hydraulic pump and two high efficiency hydrostatic drive motors.
- Foot operated dump lever allows operator to keep both hands on steering handle at all times.
- Foot actuated operating and parking brake. Heavy duty components for longer life.
Options
- Electric Start
- Foam Filled Tires
- Steel Bucket (DB17)
DB17
Type
Gas / Petrol
Engine
Honda GX390
Overall Length
97" (261.6 cm)
Overall Width (Single | Double)
35.5" (90.2 cm)
Overall Height
53" (134.6 cm)
Maximum Load
2500 lbs (1136 kg)
Capacity
17 ft^3 (481 L)
Speed
7.25 mph (11.7 km/h) at 4000 rpm
DB21
Type
Gas / Petrol
Engine
Vanguard 18hp
Overall Length
6" x 10.5" (15 x 26cm)
Overall Width (Single | Double)
43.5" (110.5 cm)
Overall Height
53" (134.6 cm)
Maximum Load
3200 lbs (1451 kg)
Capacity
21 ft^3 (595 L)
Speed
7.25 mph (11.7 km/h) at 4000 rpm
