STX6H Hydrostatic-Drive Ride-On Trowel
SKU: STX6H
STX6H Hydrostatic-Drive Ride-On Trowel comes with 70-HP Hatz Tier 4 Final Turbo Diesel, 10' Non-overlap, and twin six blade rotors. Best to call for pricing and availability.
The STX series 10-foot hydraulic trowel features innovative technology, operator comfort and ease of operation that contractors expect from the industry leader.
Drive System
- 70HP Hatz 4H50TIC turbo diesel engine complies with US EPA Tier 4 Final emission requirements
- Patented Engine Power Management senses engine load and adjusts hydraulic pump stroke to allow the engine to operate at peak performance
- Six blade spider assemblies assure the flattest floors possible with 33% more blade contact
Operator Controls
- Cruise control reduces operator fatigue during low speed operations
- 6 LED lights provide state of the art illumination for night time or indoor work
- Retardant spray system actuated by the controls located on the steering handles, provides uniform coverage of the slab surface
- Proportional hydraulic steering has been enhanced and offers improved responsiveness with minimal operator effort
- SmartPitch control synchronizes blade pitch for both rotors with single button
- Multifunction display provides the operator with easy-to-read data including engine speed, fuel levels and alerts
- 12 Volt outlet and drink holder for charging your electronic devices and operator convenience
Design
- Clamshell deign simplifies maintenance and permits convenient access to all service items
- Automatic Shut-down stops the rotors from turning if the operator stands up while the engine is running
- Increased chassis rigidity and stability achieved by lower center of gravity, reduces body roll and improves steering feedback and operator control
| Engine | Hatz 4H50TIC turbo diesel engine | |
| Engine Cooling | liquid | |
| Blades per Rotor | 6 | |
| Rotor RPM | 10-130 | |
| Path Width | 117 in | 2971 mm |
| Fuel Tank Capacity | 20 gal | 75.7 L |
| Run Time | 3.4 gal/hr | |
| Operating Weight | 2544 lb | 1158 kg |
| Shipping Weight | 3044 lb | 1380 kg |
Notice: Features and equipment specifications are subject to change without notice.
