20-Gallon Two Stage Gasoline Air Compressor - AM2-PH09-20M
SKU: AM2-PH09-20M
20-Gallon Two Stage Gasoline Air Compressor - AM2-PH09-20M designed to maximize productivity
This model features a powerful and efficient two stage compressor designed to maximize productivity. The versatility of the 20-gallon air compressor offers extra air storage and comes in stationary or portable models.
Compressor Pump:Splash lubricated · Stainless-steel braided discharge hose · Large canister intake filter · Oil level sight indicator
Frame:Powder coated ASME coded 20-gallon receiver tank · 3/16-inch base plate to reduce vibration · 14-gauge powder coated two-piece belt guard · 13-inch flat-free tires
Components:Regulator and two gauges for tank and outlet pressure · Manual drain valves for proper maintenance · 16 1/2-inch fly wheel · Quality pilot valve unloader
*Equipped with 150-PSI maximum rated regulator
Specifications
-
CFM @ 175 PSI*
17.2
-
Displacement/ Engine
270cc Honda GX270 OHV
-
Compressor
Two Stage, Cast Iron
-
Tank Size
20 gallon
-
Engine Idle Control
Pneumatic
Weights & Dimensions
-
Net Weight
306.00 lbs.
-
Shipping Weight
356.00 lbs.
-
Length
46.00 in.
-
Width
26.00 in.
-
Height
39.50 in.
Options
-
AX-0003 Manual Drain/Regulator/Metal Bowl
Drains moisture from air system
-
AX-0015 Electric Start - Battery and Cables Not Included
For easy starting
-
IX-0055 Remote Start/Choke
Remote start/choke; 6-foot wire extension for key switch; you will also need to order electric start option, AX-0015
-
IX-0059 Remote Start/Choke
Remote start/choke; 6-foot wire extension for key switch, sealed cable; you will also need to order electric start option, AX-0015
-
AX-0017 Electric Start - Battery and Cables Included
For easy starting
