Dual Power Tote Lifter

Dual Power Tote Lifter designed to lift open bottom skids, boxes, and baskets. Lifter is DC powered with rocker switch to raise or lower.

This DC powered unit includes an on-board battery charger. The side stabilizers lock lift in place when load is raised to 15-3/4". Ideal for maintenance and commercial applications. This unit can be used as manual hand pump lift or electric powered lift. Ideal when power is not available. High quality hydraulic pump and DC lift system. Compact design and strong steel profile construction. Powered with one (1) 12V battery. Integral battery charger, battery level gauge, and adjustable lowering speed. Single stage cylinder, no risk of leakage and sudden dropping of 2nd stage cylinder. The compact structure with battery and power unit positioned between body and lifting cylinder resulting in a low center of gravity and excellent maneuverability. Ergonomic design handle for simple and comfortable operation.

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

Tote Lifters
Model	Image	PDF's	Operation	Fork Size (WxL)	Service Range	Capacity (lbs)	Wt (lbs)
L-270-DP-HD			Hand Pump/12V DC Powered	27"x47"	3-11/32" to 31"	2,200	368

KEY: = Approval Drawing -- = Warranty -- = Testing Certificate
