Two Stage Filtering System with Jet-Pulse Filter Cleaning by Innotech and Bartell Global

Features

  • The HD1 is a one-motor HEPA dust extractor, that features a two-stage filtering system comprised of a main conical filter and a HEPA filter
  • "Reverse-air" jet-pulse filter cleaning system - effectively cleans and removes dust build-up on the filters
  • Easy to use "Inlet closure door" - eliminates the need to remove hoses when pulsing and cleaning filters
  • Easily connects to hand-operated power tools to extract concrete dust while cutting and grinding
  • Equipped with a "Continuous Bag" disposal system for effective dust collecting

TECHNICAL SPECS

Volts

120v


Inlet

50mm


Power (HP)

1.6 HP


Amps

8


Air Flow (cfm)

120


Water lift (inches)

100


Pre-filter (f8)

16 ft2, >99.5% @1.0um


HEPA Filter (H13)

13 ft2, >99.99% @0.3um


Dimensions

24.7" x 16.5" x 40.2"


Weight

88lbs
